Bally Refrigerated Boxes BB Medium Profile Unit Coolers User Manual

Medium profile bb unit coolers, Electric defrost, Product data & installation

background image

Electric Defrost

Medium Profile
BB Unit Coolers

CONTENTS PAGE

Nomenclature.....................................
Capacity Data.....................................
Electrical Data....................................
Wiring Diagrams................................
Dimensional Data...............................
Alco TXV Selections...........................
Sporlan TXV Selections.....................
Pictorial Views....................................
Application..........................................
Installation..........................................
Inspection...........................................
Location..............................................
Mounting.............................................
Drain Line...........................................
Piping..................................................
Wiring.................................................
System Check....................................
Maintenance.......................................
Service Parts List...............................
Project Information............................

Medium and low Temp Applications
(-30

°

F Room Temp. or Higher)

Electrical Power: Three Phase

* Heavy gauge textured aluminum cabinet
construction resists scratches/corrosion and
minimizes weight for shipment, installation and
service.

* Attractive and durable high density polyethylene
fan guards with built-in throw boosters.

* 3/8 Tubing coil construction (reduces operating
charge).

* VENTURI-FLO Distributor eliminates need for
distributor nozzle selections.

* Adjustable Defrost Termination Thermostat with
dual Fan Delay function.

* Stainless-Steel Defrost Heaters mounted on the
coil for service accessibility

* Refrigerants R12, R22, R502, R134a, R404A,
R407A, R407B, R407C, R507.

Bulletin: B30-BBE-PDI-15
1048680

PRODUCT DATA &
INSTALLATION

Cover

2,3
2,3
4,5

6
7
8
9
9
9
9
9

10
10
10
10
10
10

11

Back

BALLY
MEDIUM PROFILE
UNIT COOLER

NUMBER OF FANS

NOMENCLATURE

MBH CAPACITY AT
10

o

F T.D. (60Hz)

SIZE 24 = 24,000 BTUH
OF COOLING

OPTIONS
P = PRE ASSEMBLED REMOTE
S = STANDARD UNIT

DEFROST
ED = ELECTRIC DEFROST

ELECTRICAL
T3 = 208-230/3/60 T4 = 460/3/60
T5 = 575/3/60 T7 = 200-220/3/50
T8 = 380/3/60 T9 = 380-400/3/50

REVISION LEVEL

BB

1

24

P

-ED-

T4 B
