- 14 -
GENERAL SPECIFICATIONS - 550 RPM MODELS - R22
NOTES:
(1) For R407A, R507 use R22 Charge x 0.87. For R407-C use R22 Charge x 0.97.
For R134a and R502 use R22 Charge. For R12 use R22 Charge x 1.1.
(2) Normal Charge is the refrigerant charge for warm ambient or summer operation. For low ambient
or winter charge with flooded head pressure control and fan cycling see Page 33 and Page 34.
(3) 90% FULL is the liquid refrigerant weight at 90% of internal volume and is for reference ONLY.
(4) For 50Hz Fan data use 60Hz CFM (m 3 /h) x 0.83.capacity multiply by 0.92.
(5) Less weight pf refrigerant charge.
BVC
MODEL
NUMBER
Total No.
of Feeds
R22 Refrigerant Charge (1)
Air Flow Rate (4)
Piping Connections
Condenser Weight (5)
Normal (2) 90% FULL (3) Inlet
Qty - OD
Outlet
Qty - OD lbs kg lbs kg CFM m 3 /h lbs kg
Single Row Models
1B11 007 4 1.7 0.8 11.0 5.2 4630 7900 1 - 1 1/8 1 - 7/8 360 163
1B11 009 8 2.2 1.0 17.0 7.5 4060 6900 1 - 1 3/8 1 - 7/8 375 170
1B11 010 9 2.8 1.3 21.0 9.5 4630 7900 1 - 1 3/8 1 - 7/8 420 191
1B11 011 8 3.9 1.8 27.0 12.0 4450 7600 1 - 1 3/8 1 - 1 1/8 440 200
1B11 012 8 4.3 2.0 31.0 14.0 4660 7900 1 - 1 3/8 1 - 1 1/8 480 218
1B11 013 10 5.2 2.4 39.0 18.0 4480 7600 1 - 1 5/8 1 - 1 1/8 505 229
1B12 017 14 4.1 1.9 31.0 14.0 8100 13800 1 - 1 5/8 1 - 1 1/8 565 256
1B12 019 18 6.1 2.8 44.0 20.0 9300 15700 1 - 2 1/8 1 - 1 3/8 630 286
1B12 022 18 7.4 3.4 55.0 25.0 8900 15100 1 - 2 1/8 1 - 1 3/8 675 306
1B12 024 18 8.3 3.8 62.0 28.0 9300 15800 1 - 2 1/8 1 - 1 3/8 740 336
1B12 027 18 10.0 4.5 75.0 34.0 9000 15300 1 - 2 1/8 1 - 1 3/8 790 358
1B13 029 18 9.0 4.1 61.0 28.0 13800 23500 1 - 2 1/8 1 - 1 5/8 840 381
1B13 034 24 10.0 4.5 78.0 35.0 13300 22700 1 - 2 1/8 1 - 1 5/8 905 410
1B13 037 24 12.0 5.4 94.0 42.0 14000 23800 1 - 2 5/8 1 - 1 5/8 1000 454
1B13 041 30 14.0 6.4 113 51.0 13500 22900 1 - 2 5/8 1 - 1 5/8 1070 485
1B13 043 36 17.5 7.9 128 57.8 17100 29200 1 - 2 5/8 1 - 1 5/8 1055 479
1B13 048 45 20.5 9.3 152 68.9 16700 28300 1 - 2 5/8 1 - 1 5/8 1150 522
2B14 056 15 25.9 11.8 183 83.2 23200 39500 1 - 2 5/8 1 - 2 1/8 1600 726
2B14 063 20 32.5 14.7 239 108 22800 38800 1 - 2 5/8 1 - 2 1/8 1650 748
2B14 068 25 38.0 17.2 286 130 22200 37700 1 - 2 5/8 1 - 2 1/8 1750 794
2B15 079 30 38.5 17.5 290 131 28500 48500 1 - 2 5/8 1 - 2 1/8 2063 936
2B15 085 37 48.8 22.2 356 161 27700 47200 1 - 2 5/8 1 - 2 5/8 2188 992
2B16 095 30 53.5 24.3 365 165 34200 58200 1 - 3 1/8 1 - 3 1/8 2475 1123
2B16 103 37 61.2 27.7 436 198 33300 56600 1 - 3 1/8 1 - 3 1/8 2625 1191
Double Row Models
1B22 039 27 16.0 7.3 104 47.0 18500 31500 2 - 2 1/8 2 - 1 3/8 1060 481
1B22 045 36 19.0 8.6 126 57.0 17800 30300 2 - 2 1/8 2 - 1 3/8 1145 519
1B22 049 36 21.0 9.5 141 64.0 18600 31700 2 - 2 1/8 2 - 1 3/8 1255 569
1B22 054 45 23.0 10.0 167 76.0 17900 30500 2 - 2 1/8 2 - 1 3/8 1350 612
1B23 058 36 22.0 10.0 141 64.0 27700 47100 2 - 2 1/8 2 - 1 5/8 1420 644
1B23 067 48 26.0 12.0 174 79.0 26700 45300 2 - 2 1/8 2 - 1 5/8 1550 703
1B23 073 48 30.0 14.0 212 96.0 28000 47500 2 - 2 5/8 2 - 1 5/8 1710 776
1B23 081 60 35.0 16.0 251 114 26900 45800 2 - 2 5/8 2 - 1 5/8 1865 846
1B23 086 72 35.0 16.0 255 116 34300 58300 2 - 2 5/8 2 - 1 5/8 2110 957
1B23 096 90 41.0 19.0 304 138 33300 56700 2 - 2 5/8 2 - 1 5/8 2300 1043
2B24 112 30 53.0 24.0 375 170 46500 79000 2 - 2 5/8 2 - 2 1/8 3200 1451
2B24 126 40 65.0 30.0 477 217 45600 77600 2 - 2 5/8 2 - 2 1/8 3300 1497
2B24 137 50 77.0 35.0 579 263 44400 75500 2 - 2 5/8 2 - 2 1/8 3500 1588
2B25 158 60 77.0 35.0 579 263 57000 96900 2 - 2 5/8 2 - 2 1/8 4125 1871
2B25 172 75 99.0 45.0 721 327 55500 94300 2 - 2 5/8 2 - 2 5/8 4375 1984
2B26 190 60 107.0 49.0 729 331 68400 116300 2 - 3 1/8 2 - 3 1/8 4950 2245
2B26 206 75 124.0 56.0 883 401 66600 113200 2 - 3 1/8 2 - 3 1/8 5250 2381
