R404a – Bally Refrigerated Boxes BVC Generation C – Direct Drive Air-Cooled – Vertical Air User Manual
Page 3

CAPACITY DATA - 850 RPM MODELS - R404A
- 3 -
To calculate capacities with other refrigerants, multiply the R22 capacity by the appropriate correction factor.
Refer to the table accompanying each of the R22 tables.
NOTES:
(1)
Above capacity data based on 0°F subcooling and at sea level.
(2)
TD = Condensing temperature - ambient temperature
(3)
Standard fin spacing is 12 FPI except models 056 and 112 (13 FPI).
(4)
For High Altitude applications apply the following correction factors:
0.94 for 2000 feet, 0.88 for 4000 feet and 0.81 for 6000 feet.
(5)
For 50Hz capacity multiply by 0.92.
BVC
MODEL
NUMBER
Fan Rows
TOTAL HEAT OF REJECTION CAPACITY (MBH)
Maximum
No. of
Feeds
MBH
@ 1° F TD
Per Feed
(12 FPI)
TEMPERATURE DIFFERENCE (TD)
12 FPI
10 FPI
8 FPI
1°F
(0.56°C)
10°F
(5.56°C)
15°F
(8.3°C)
20°F
(11.1°C)
30°F
(16.7°C)
1°F
(0.56°C)
1°F
(0.56°C)
Single Row Models
007
1 x 1
3.070
30.7
46.1
61.4
92.1
2.825
2.517
7
0.44
009
1 x 1
4.011
40.1
60.2
80.2
120
3.731
3.410
8
0.50
010
1 x 1
4.515
45.2
67.7
90.3
135
4.199
3.838
9
0.50
011
1 x 1
5.204
52.0
78.1
104
156
4.944
4.579
12
0.43
012
1 x 1
5.699
57.0
85.5
114
171
5.414
5.015
12
0.47
013
1 x 1
6.271
62.7
94.1
125
188
6.146
5.770
15
0.42
017
1 x 2
8.017
80.2
120
160
241
7.455
6.814
14
0.57
019
1 x 2
8.987
89.9
135
180
270
8.358
7.639
18
0.50
022
1 x 2
10.41
104
156
208
312
9.892
9.164
24
0.43
024
1 x 2
11.41
114
171
228
342
10.84
10.04
24
0.48
027
1 x 2
12.55
125
188
251
376
12.30
11.54
30
0.42
029
1 x 3
13.55
135
203
271
406
12.51
11.51
27
0.50
034
1 x 3
15.58
156
234
312
467
14.80
13.71
36
0.43
037
1 x 3
17.11
171
257
342
513
16.25
15.05
36
0.48
041
1 x 3
18.82
188
282
376
565
18.44
17.31
45
0.42
043
1 x 3
20.02
200
300
400
601
19.02
17.62
36
0.56
048
1 x 3
22.32
223
335
446
670
21.87
20.53
45
0.50
056
1 x 4
25.55
256
383
511
767
23.77
21.72
22
1.16
063
1 x 4
29.38
294
441
588
881
27.91
25.85
30
0.98
068
1 x 4
31.58
316
474
632
947
30.94
29.05
37
0.85
079
1 x 5
36.81
368
552
736
1104
34.97
32.39
30
1.23
085
1 x 5
39.48
395
592
790
1184
38.69
36.32
37
1.07
095
1 x 6
44.17
442
663
883
1325
41.96
38.87
30
1.47
103
1 x 6
47.37
474
711
947
1421
46.41
43.58
37
1.28
Double Row Models
039
2 x 2
18.04
180
271
361
541
16.78
15.34
36
0.50
045
2 x 2
20.82
208
312
416
625
19.78
18.32
48
0.43
049
2 x 2
22.80
228
342
456
684
21.66
20.06
48
0.47
054
2 x 2
25.06
251
376
501
752
24.56
23.05
60
0.42
058
2 x 3
27.06
271
406
541
812
25.17
23.00
54
0.50
067
2 x 3
31.20
312
468
624
936
29.64
27.46
72
0.43
073
2 x 3
34.18
342
513
684
1025
32.47
30.08
72
0.47
081
2 x 3
37.60
376
564
752
1128
36.85
34.59
90
0.42
086
2 x 3
40.05
400
601
801
1201
38.04
35.24
72
0.56
096
2 x 3
44.64
446
670
893
1339
43.75
41.07
90
0.50
112
2 x 4
52.27
523
784
1045
1568
48.61
44.43
45
1.16
126
2 x 4
58.75
588
881
1175
1763
55.82
51.70
60
0.98
137
2 x 4
64.01
640
960
1280
1920
62.73
58.88
75
0.85
158
2 x 5
73.62
736
1104
1472
2209
69.94
64.78
60
1.23
172
2 x 5
80.02
800
1200
1600
2401
78.42
73.62
75
1.07
190
2 x 6
88.34
883
1325
1767
2650
83.93
77.74
60
1.47
206
2 x 6
96.02
960
1440
1920
2881
94.10
88.34
75
1.28
