CAPACITY DATA - 1140 RPM MODELS - R22
NOTES:
(1)
Above capacity data based on 0°F subcooling and at sea level.
(2)
TD = Condensing temperature - ambient temperature
(3)
Standard fin spacing is 12 FPI except models 056 and 112 (13 FPI).
(4)
For High Altitude applications apply the following correction factors:
0.94 for 2000 feet, 0.88 for 4000 feet and 0.81 for 6000 feet.
(5)
For 50Hz capacity multiply by 0.92.
Correction Factors for Other refrigerants - Use R22 Values Multiplied By
R134a
R12
R507
R404A
R407A
R407B
R502
R407C
0.94
0.95
0.97
0.97
0.97
0.97
0.98
1.00
BVC
MODEL
NUMBER
Fan Rows
TOTAL HEAT OF REJECTION CAPACITY (MBH)
Maximum
No. of
Feeds
MBH
@ 1° F TD
Per Feed
(12 FPI)
TEMPERATURE DIFFERENCE (TD)
12 FPI
10 FPI
8 FPI
1°F
(0.56°C)
10°F
(5.56°C)
15°F
(8.3°C)
20°F
(11.1°C)
30°F
(16.7°C)
1°F
(0.56°C)
1°F
(0.56°C)
Single Row Models
007
1 x 1
3.627
36.3
54.4
72.5
109
3.303
2.911
7
0.52
009
1 x 1
4.989
49.9
74.8
100
150
4.677
4.220
8
0.62
010
1 x 1
5.516
55.2
82.7
110
165
5.094
4.572
9
0.61
011
1 x 1
6.446
64.5
96.7
129
193
6.118
5.589
12
0.54
012
1 x 1
7.157
71.6
107
143
215
6.710
6.114
12
0.60
013
1 x 1
7.985
79.9
120
160
240
7.678
7.095
15
0.53
017
1 x 2
9.971
100
150
199
299
9.348
8.434
14
0.71
019
1 x 2
10.98
110
165
220
329
10.14
9.100
18
0.61
022
1 x 2
12.90
129
194
258
387
12.25
11.19
24
0.54
024
1 x 2
14.34
143
215
287
430
13.44
12.25
24
0.60
027
1 x 2
15.98
160
240
320
479
15.37
14.20
30
0.53
029
1 x 3
16.55
166
248
331
497
15.29
13.72
27
0.61
034
1 x 3
19.31
193
290
386
579
18.33
16.74
36
0.54
037
1 x 3
21.49
215
322
430
645
20.15
18.36
36
0.60
041
1 x 3
23.96
240
359
479
719
23.04
21.29
45
0.53
043
1 x 3
25.40
254
381
508
762
24.03
21.94
36
0.71
048
1 x 3
28.48
285
427
570
854
27.14
25.19
45
0.63
056
1 x 4
31.01
310
465
620
930
28.64
25.71
22
1.41
063
1 x 4
36.76
368
551
735
1103
34.77
31.76
30
1.23
068
1 x 4
40.34
403
605
807
1210
38.44
35.67
37
1.09
079
1 x 5
46.06
461
691
921
1382
43.57
39.79
30
1.54
085
1 x 5
50.43
504
756
1009
1513
48.06
44.59
37
1.36
095
1 x 6
55.27
553
829
1105
1658
52.29
47.75
30
1.84
103
1 x 6
60.51
605
908
1210
1815
57.66
53.51
37
1.64
Double Row Models
039
2 x 2
22.04
220
331
441
661
20.35
18.27
36
0.61
045
2 x 2
25.79
258
387
516
774
24.48
22.37
48
0.54
049
2 x 2
28.63
286
429
573
859
26.84
24.45
48
0.60
054
2 x 2
31.92
319
479
638
957
30.69
28.36
60
0.53
058
2 x 3
33.06
331
496
661
992
30.53
27.40
54
0.61
067
2 x 3
38.65
386
580
773
1159
36.69
33.52
72
0.54
073
2 x 3
42.93
429
644
859
1288
40.25
36.67
72
0.60
081
2 x 3
47.89
479
718
958
1437
46.05
42.55
90
0.53
086
2 x 3
50.80
508
762
1016
1524
48.06
43.89
72
0.71
096
2 x 3
56.97
570
854
1139
1709
54.29
50.38
90
0.63
112
2 x 4
63.44
634
952
1269
1903
58.58
52.58
45
1.41
126
2 x 4
73.52
735
1103
1470
2205
69.55
63.51
60
1.23
137
2 x 4
81.76
818
1226
1635
2453
77.92
72.30
75
1.09
158
2 x 5
92.12
921
1382
1842
2764
87.15
79.59
60
1.54
172
2 x 5
102.2
1022
1533
2044
3067
97.41
90.39
75
1.36
190
2 x 6
110.5
1105
1658
2211
3316
104.6
95.50
60
1.84
206
2 x 6
122.7
1227
1840
2453
3680
116.9
108.5
75
1.64
