Bally Refrigerated Boxes BVC Generation C – Direct Drive Air-Cooled – Vertical Air - Manual (Page 12)

- 12 -
CAPACITY DATA - 550 RPM MODELS - R22
NOTES:
(1) Above capacity data based on 0°F subcooling and at sea level.
(2) TD = Condensing temperature - ambient temperature
(3) Standard fin spacing is 12 FPI except models 056 and 112 (13 FPI).
(4) For High Altitude applications apply the following correction factors:
0.94 for 2000 feet, 0.88 for 4000 feet and 0.81 for 6000 feet.
(5) For 50Hz capacity multiply by 0.92.
Correction Factors for Other refrigerants - Use R22 Values Multiplied By
BVC
MODEL
NUMBER
Fan Rows
TOTAL HEAT OF REJECTION CAPACITY (MBH)
Maximum
No. of
Feeds
MBH
@ 1° F TD
Per Feed
(12 FPI)
TEMPERATURE DIFFERENCE (TD)
12 FPI 10 FPI 8 FPI
1°F
(0.56°C)
10°F
(5.56°C)
15°F
(8.3°C)
20°F
(11.1°C)
30°F
(16.7°C)
1°F
(0.56°C)
1°F
(0.56°C)
Single Row Models
007 1 x 1 2.540 25.4 38.1 50.8 76.2 2.324 2.059 4 0.63
009
1 x 1 3.162 31.6 47.4 63.2 94.8 3.011 2.760 8 0.40
010 1 x 1 3.523 35.2 52.8 70.5 106 3.312 3.014 9 0.39
011 1 x 1 3.949 39.5 59.2 79.0 118 3.822 3.568 8 0.49
012 1 x 1 4.298 43.0 64.5 86.0 129 4.104 3.835 8 0.54
013 1 x 1 4.580 45.8 68.7 91.6 137 4.503 4.288 10 0.46
017 1 x 2 6.316 63.2 94.7 126 189 6.015 5.514 14 0.45
019 1 x 2 7.008 70.1 105 140 210 6.589 5.997 18 0.39
022 1 x 2 7.898 79.0 118 158 237 7.644 7.136 18 0.44
024 1 x 2 8.603 86.0 129 172 258 8.215 7.677 18 0.48
027 1 x 2 9.159 91.6 137 183 275 9.006 8.575 18 0.51
029 1 x 3 10.56 106 158 211 317 9.930 9.037 18 0.59
034
1 x 3 11.82 118 177 236 355 11.44 10.68 24 0.49
037 1 x 3 12.89 129 193 258 387 12.31 11.51 24 0.54
041 1 x 3 13.73 137 206 275 412 13.50 12.86 30 0.46
043 1 x 3 15.24 152 229 305 457 14.17 13.32 36 0.42
048 1 x 3 16.20 162 243 324 486 15.59 14.92 45 0.36
056
1 x 4 20.23 202 303 405 607 19.02 17.32 15 1.35
063 1 x 4 22.53 225 338 451 676 21.52 20.10 20 1.13
068 1 x 4 23.66 237 355 473 710 23.26 22.15 25 0.95
079 1 x 5 28.24 282 424 565 847 26.97 25.19 30 0.94
085 1 x 5 29.18 292 438 592 887 28.69 27.32 37 0.79
095
1 x 6 33.88 339 508 678 1017 32.36 30.23 30 1.13
103 1 x 6 35.02 350 525 710 1065 34.42 32.78 37 0.95
Double Row Models
039 2 x 2 14.06 141 211 281 422 13.22 12.03 27 0.52
045 2 x 2 15.79 158 237 316 474 15.28 14.27 36 0.44
049
2 x 2 17.18 172 258 344 515 16.40 15.33 36 0.48
054 2 x 2 18.29 183 274 366 549 17.98 17.12 45 0.41
058 2 x 3 21.09 211 316 422 633 19.83 18.05 36 0.59
067 2 x 3 23.66 237 355 473 710 22.90 21.37 48 0.49
073 2 x 3 25.76 258 386 515 773 24.60 22.99 48 0.54
081 2 x 3 27.44 274 412 549 823 26.98 25.69 60 0.46
086 2 x 3 30.48 305 457 610 914 28.34 26.63 72 0.42
096 2 x 3 32.39 324 486 648 972 31.18 29.85 90 0.36
112 2 x 4 40.46 405 607 809 1214 38.03 34.63 30 1.35
126 2 x 4 45.07 451 676 901 1352 43.04 40.20 40 1.13
137 2 x 4 47.32 473 710 946 1420 46.52 44.29 50 0.95
158
2 x 5 56.47 565 847 1129 1694 53.93 50.38 60 0.94
172 2 x 5 59.16 592 887 1183 1775 58.15 55.37 75 0.79
190 2 x 6 67.77 678 1017 1355 2033 64.72 60.45 60 1.13
206 2 x 6 70.98 710 1065 1420 2129 69.78 66.44 75 0.95
R134a R12 R507 R404A R407A R407B R502 R407C
0.94 0.95 0.97 0.97 0.97 0.97 0.98 1.00
