WINCUE USER GUIDE
APPENDIX B
87
AUTOCUE LTD. 2002
appears as an 8-pin connector on Issue 1 cards, and a 3-pin connector on
Issue 2 cards.
If you need further information about powering the I.M.T. card from an
external power supply please contact your supplier.
B6 Composite Video Features Connector - J10
The Composite Video Features connector allows additional 4 composite
video ports to be added to your PC. To find out more about this product
contact your supplier.
Do not attach anything to any of the pins on J10.
B6 Other Jumpers
J1 and J5
J1 is the debug port. It supplies serial debugging information. Do not attach
anything to any of its pins.
J5 is the flash reset port. Do not attach anything to any of its pins.
