Contents I
C
ONTENTS
Chapter 1 Introduction
1.1
Intended Audience........................................................................................... 1-1
1.2 Other Required Manuals ................................................................................. 1-1
Chapter 2 About the Drive and Cabinet
2.1
Identifying the Solar Turbine Drive by Model Number and Ratings................. 2-1
2.2 Enclosure Rating ............................................................................................. 2-2
2.3 Identifying Solar Turbine Cabinet Components ............................................... 2-2
Chapter 3 Cabinet Mounting and Wire Routing
3.1
Mounting the Drive .......................................................................................... 3-1
3.1.1 Verifying the Drive’s Watts Loss Rating ................................................ 3-2
3.2 Cabinet Wire Routing ...................................................................................... 3-3
3.3 Grounding the Cabinet .................................................................................... 3-6
Chapter 4 Installing Power Wiring
4.1
Installing Fuses for Branch Circuit Protection.................................................. 4-1
4.2 Installing a Required External/Separate Input Disconnect .............................. 4-1
4.3 Installing Power Wiring from the DC Power Supply to the Drive’s Internal
DC Bus Terminals ........................................................................................... 4-3
4.4 Recommended Motor Lead Lengths ............................................................... 4-5
Chapter 5 Troubleshooting the Drive
5.1
Verifying that DC Bus Capacitors are Discharged........................................... 5-1
5.2 Replacement Parts .......................................................................................... 5-1
Appendix A Solar Turbine Drive Parameters ...............................................................................A-1
