Hapter, About the drive and cabinet – Rockwell Automation Solar Turbine Addendum Version 6.0 User Manual
Page 11

About the Drive and Cabinet
2-1
C
HAPTER
2
About the Drive and Cabinet
This chapter describes how to identify the Solar Turbine drive and cabinet layout using
the Solar Turbine model number and drive power ratings. Internal cabinet component
drawings are also provided.
2.1
Identifying the Solar Turbine Drive by Model Number
and Ratings
The Solar Turbine drive is available in 1 HP and 5 HP versions. Each drive can be
identified by its model number. See figure 2.1. This number appears on the shipping
label and on the drive’s nameplate. The drive’s model number includes the Power
Module and the Regulator. Drive power ratings are provided in table 2.1.
Figure 2.1 – Identifying the Drive Model Number
Horsepower Ratings
Regulator Type
Voltage
Enclosure
1 = NEMA 1
Regulator Version
60 = Version 6.0
Hardware Version
S =Special
0 = 120V DC
N
N
A
N
NN
N
G = V/Hz only
Table 2.1 – Drive Ratings
Drive
M/N
Enclosure
Type
Output
Power
Input
Volts
Input
Amps
Output
Volts
Output
Amps
Output
Frequency
1G0160S
NEMA 1
IP20 V6.04
1 HP
120 VDC
13.4 A
90 VAC
11.1 A
3 to 200 Hz
5G0160S
NEMA 1
IP20 V6.04
5 HP
120 VDC
37.0 A
90 VAC
30.4 A
3 to 200 Hz
