PowerFlex® 700S and 700H Frame 13 Replacement Power Structures
17
ASIC Board Connections
Connect this component:
termination point …
to this component : termination point
ASIC Board: H1 (fiber optic connector) Fiber Optic Adapter Board: H1 (fiber optic connector)
ASIC Board: H2 (fiber optic connector) Fiber Optic Adapter Board: H2 (fiber optic connector)
ASIC Board: H3 (fiber optic connector) Fiber Optic Adapter Board: H3 (fiber optic connector)
ASIC Board: H4 (fiber optic connector) Fiber Optic Adapter Board: H4 (fiber optic connector)
ASIC Board: H5 (fiber optic connector) Fiber Optic Adapter Board: H5 (fiber optic connector)
ASIC Board: H6 (fiber optic connector) Fiber Optic Adapter Board: H6 (fiber optic connector)
ASIC Board: H7 (fiber optic connector) Fiber Optic Adapter Board: H7 (fiber optic connector)
ASIC Board: X10
Fiber Optic Adapter Board: X2
