Safety Function: Hinge Switch 5
Rockwell Automation Publication SAFETY-AT096A-EN-P – November 2013
Functional Safety Description
Door Monitoring Function
When the door is opened, the hinge switch opens its two safety contacts. When the
hinge switch turns off, the Guardmaster dual-input safety relay (GSR DI) responds by
opening its safety contacts (13...14 and 23…24), de-energizing the coils of K1 and
K2. With power removed, hazardous motion coasts to a stop (Stop Category 0).
Hazardous motion cannot be started until the door is closed and the Reset button is
pressed and released.
E-stop Function
The pulsed outputs of the relay (terminals S11 and S21) are run separately through
the two E-stop contacts to the input terminals S12 and S22, respectively. When the
E-stop is pressed, these two circuits are interrupted. The relay responds to this
circuit interruption by opening its safety contacts (13…14 and 23…24), de-energizing
the coils of K1 and K2. With power removed, hazardous motion coasts to a stop
(Stop Category 0). Hazardous motion cannot be started until the E-stop is released
and the Reset button is pressed and released.
Bill of Material
This application uses these products.
Cat. No. Description Quantity
800F-1YP8 800F 1-hold enclosure E-stop station, plastic, PG,
twist-to-release 60 mm, non-illuminated, 1 N.O. contact,
2 N.C. contacts
1
440H-E22027 Hinge switch - Ensign 3: contacts: (safety/aux) 2 N.C.
contacts, 1 N.C. contact, BBM preference: actuator
shaft: length 80 mm diameter: 10 mm-solid, conduit
entry: M16 conduit
1
800FM-G611MX10 800F push button – metal, guarded, blue, R, metal latch
mount, 1 N.O. contact, 0 N.C. contacts, standard,
standard pack (quantity 1)
1
400R-D22R2 Guardmaster dual-input safety relay, 2 dual-channel
universal inputs, 1 N.C. contact, solid-state auxiliary
output
1
100S-C09EJ23BC Modular control system (MCS) 100S-C safety contactor,
9 A, 24V DC (with electrical coil), bifurcated contact
2
