What this kit contains – Rockwell Automation 20D PowerFlex 700S/700H Frame 10...14 Drives Maintenance Stand User Manual
Page 2

Publication PFLEX-IN014B-EN-P
2
What This Kit Contains
LE
FT
FR
10
FR
12
LEFT
FR11
LEFT
FR11
L
E
F
T
F
R
1
1
LEFT
FR13
LEFT
FR13
16
4X
17 4X
6
5
1
3
11
13
2
15
2X
14 4X
19 2X
18 4X
12
10
9
19 2X
18 4X
14 2X
7
8
20
2X
4
No. Description
Qty.
Left Rail
1
Right Rail
1
Top Bracket
1
Base
1
Frame 10/12 Left Mounting Plate
1
Frame 10/12 Right Mounting Plate 1
Frame 11 Left Mounting Plate
1
Frame 11 Right Mounting Plate
1
Frame 13/14 Left Mounting Plate
1
Frame 13/14 Right Mounting Plate 1
Inner Leg
2
Outer Leg
2
Locking Pin
2
M8 x 20 Phillips Screw
6
M8 x 40 Phillips Screw
2
M5 x 16 Phillips Screw
18
(1)
(1)
4 Screws for Frame 10/12 Drives, 6 Screws for
Frame 11 Drives, 8 Screws for Frame 13/14
Drives
M8 x 50 Phillips Screw
4
M8 x 60 Phillips Screw
8
M8 Flat Washer
4
Leveling Foot
2
1
2
3
4
5
6
7
8
1
9
10
11
12
13
14
15
16
17
18
19
20
