OEM Parameter Description Notes
TICS_CHASSIS The number of the
Trusted
TM Chassis where
the primary I/O module is
installed
The Trusted TM Controller Chassis is 1,
and Trusted TM Expander Chassis are 2
to 15
TICS_SLOT The slot number in the
chassis where the primary
I/O module is installed The I/O module slots in the Trusted TM
Controller chassis are numbered from 1
to 8. The I/O Module slots in the
Trusted
TM Expander Chassis are
numbered from 1 to 12
Table 4 OEM Parameters
3.2.1. Rack 1: THRSHIN
This board allows the current thresholds for an analogue input channel to be read by the application,
under control of the THRSHOUT board (see section 3.2.4.
Channel Description
1 Channel number being read. Range 1 to
20.
2 States 2 > 1 falling threshold
3 States 1 > 2 rising threshold
4 States 3 > 2 falling threshold
5 States 2 > 3 rising threshold
6 States 4 > 3 falling threshold
7 States 3 > 4 rising threshold
8 States 5 > 4 falling threshold
9 States 4 > 5 rising threshold
Table 5 Rack 1: THRSHIN descriptions
THRSHIN reads in the module threshold values controlled by THRSHOUT in Rack 4. See Table 1 for a
graphical representation of the states and thresholds.
