Rockwell Automation T8448 Trusted TMR Zone Interface Module - 40 Channel - Manual (Page 27)

Trusted
TM
Module T8448
Issue 14 Apr 10 PD-T8448 27
3.2.7. Rack 7: HKEEPING
Description
Channel
FCR Units (Full Scale Range)
1 A
2 B
3 C
24V2 Field Voltage -32768 32767 mV
4 A
5 B
6 C
Internal supply voltage (post regulator) -32768 32767 mV
7 A
8 B
9 C
Internal supply current (post regulator) -32768 32767 mA
10 A
11 B
12 C
Output voltage (post isolation) -32768 32767 mV
13 A
14 B
15 C
24V1 Field Voltage -32768 32767 mV
16 A
17 B
18 C
HIU Board Temperature
( Note: Temperature, ºC = input value / 256 )
-32768 32767 -
19 A
20 B
21 C
Front Panel Load Current -32768 32767 mA
22 A
23 B
24 C
SmartSlot Link Voltage -32768 32767 mV
25 A
26 B
27 C
FIU Power Group 1 Field Supply Voltage -32768 32767 mV
28 A
29 B
30 C
FIU Board Temperature, Group 1
( Note: Temperature, ºC = input value / 256 )
-32768 32767 -
31 A
32 B
33 C
FIU Power Group 2 Field Supply Voltage -32768 32767 mV
34 A
35 B
36 C
FIU Board Temperature, Group 2
( Note: Temperature, ºC = input value / 256 )
-32768 32767 -
37 A
38 B
39 C
FIU Power Group 3 Field Supply Voltage -32768 32767 mV
40 A
41 B
42 C
FIU Board Temperature, Group 3
( Note: Temperature, ºC = input value / 256 )
-32768 32767 -
43 A
44 B
45 C
FIU Power Group 4 Field Supply Voltage -32768 32767 mV
46 A
47 B
48 C
FIU Board Temperature, Group 4
( Note: Temperature, ºC = input value / 256 )
-32768 32767 -
49 A
50 B
51 C
FIU Power Group 5 Field Supply Voltage -32768 32767 mV
52 A
53 B
54 C
FIU Board Temperature, Group 5
( Note: Temperature, ºC = input value / 256 )
-32768 32767 -
55 A
56 B
57 C
Diagnostic error code
Table 13 Rack 7: Housekeeping descriptions
