3.2. T8448 Complex Equipment Definition
The 8448 I/O Complex Equipment Definition includes 10 I/O boards, referenced numerically by rack
number.
Rack I/O Board Description Data Type Direction No. of
Channels
OEM Parameters - - -
1 DO
Field Output Status Boolean Out 40
2 STATE Field Output State Integer In 40
3 AI Measured voltage Integer In 40
4 CI Measured current Integer In 40
5 LINE_FLT Line Fault Status Boolean In 40
6 DISCREP Channel Discrepancy Integer In 3
7 HKEEPING Housekeeping Registers Integer In 57
8 INFO I/O Module Information Integer In 11
9 THRSHIN Threshold Setting Feedback Integer In 9
10 THRSHOUT Threshold Setting Command Integer Out 11
Table 3 Complex Equipment Definition
There are two OEM parameters included in the first rack (DO Board). These OEM parameters define
the primary module position, declaring the module’s chassis and slot location. There is no need to
define the secondary module position within the IEC1131 TOOLSET if the system will always be
started with a module in the primary position. Where systems may be required to start-up with
modules in the secondary position as the active module, e.g. primary module is not installed when
application is started, the secondary module’s position should be declared in the module definition of
the System Configuration Manager.
OEM Parameter Description Notes
TICS_CHASSIS The number of the
Trusted TM Chassis
where the Primary I/O
module is installed
The Trusted TM Controller Chassis is 1, and
Trusted TM Expander Chassis are 2 to 15
TICS_SLOT The slot number in the
chassis where the
Primary I/O module is
installed The I/O module slots in the Trusted TM Controller
chassis are numbered from 1 to 8. The I/O Module
slots in the Trusted
TM Expander Chassis are
numbered from 1 to 12.
Table 4 OEM Parameters
