Motor catalog number identification – Rockwell Automation HPK-Series Asynchronous Servo Motor User Manual
Page 3
HPK-Series Asynchronous Servo Motors 3
Publication HPK-IN001C-EN-P - June 2010
Motor Catalog Number Identification
FACTORY DESIGNATED OPTIONS
A
= Standard
MOUNTING TYPE/SHAFT KEY
A
= IEC Metric, Free Mounting Holes
(Type FF), Foot and Flange Mount,
Keyed Shaft
B
= IEC Metric, Free Mounting Holes
(Type FF), Foot Mount Only, Keyed
Shaft
BRAKE
2
= No Brake
4
= 380…460V ac Brake
CONNECTORS
4
= Right-angle Rotatable
BLOWER/JUNCTION BOX
A
= Inline Blower, F3 Jx Box
B
= Top-mount Blower, F1 Jx Box
C
= Top-mount Blower, F2 Jx Box
FEEDBACK
M
= Multi-turn High Resolution Encoder
S
= Single-turn High Resolution Encoder
RATED SPEED (rpm)
C
= 1500
E
= 3000
FRAME SIZE (mm)
1307
1308
1310
1609
1611
1613
1815
2010
2212
2510
VOLTAGE RATING
B = 460V
ac
E = 400V
ac
BULLETIN
HPK = Asynchronous
Servo
HPK - B 1307 C- S A 4 2 A A
