Planning the Installation
3-7
3.2.1.3 Recommended Control and Signal Wire Sizes
The recommended wire size to connect I/O signals to the terminal strip on the AC Line
I/O board is 20 to 14 AWG, (2 to 0.5 mm
2
). Recommended terminal tightening torque
is 0.5 Newton-meters (4.5 in-lbs). Operator controls can be up to 303 meters (1000
feet) from the LiquiFlo drive.
Table 3.3 – Recommended Power Wire Sizes for B-Frame Drives
Type of Power Wiring
Drive M/N LF150414R4, LF150414W4
with kit M/N LF150414W4PM
AC Input Power (R/L1, S/L2, T/L3)
Use lugs
1
that will accept two (2) 300
MCM to 6 AWG conductors
1
Lugs not provided with standard drive. They are available as part of kit M/N LF150414W4PM.
Output Power (U/T1, V/T2, W/T3)
Delta-Wye Transformer (S1 to S6)
Ground (PE)
Table 3.4 – Recommended Power Wire Sizes for C-Frame Drives
Type of Power Wiring
Drive M/N LF150500R4, LF150500W4,
LF150643R4, or LF150643W4
with kit M/N LF150643W4PM
AC Input Power (R/L1, S/L2, T/L3)
Use lugs
1
that will accept two (2) 350
MCM to 4 AWG conductors
1
Lugs not provided with standard drive. They are available as part of kit M/N LF150643W4PM.
Output Power (U/T1, V/T2, W/T3)
Delta-Wye Transformer (S1 to S6)
Ground (PE)
Table 3.5 – Recommended Power Wire Sizes for D-Frame Drives
Type of Power Wiring
Drive M/N LF151200R4, LF151200W4
with kit M/N LF151200W4PM
AC Input Power (R/L1, S/L2, T/L3)
Use lugs
1
that will accept two (2) 800
MCM to 300 MCM conductors
1
Lugs not provided with standard drive. They are available as part of kit M/N LF151200W4PM.
Output Power (U/T1, V/T2, W/T3)
Delta-Wye Transformer (S1 to S6)
Ground (PE)
