Page 12

2-2
LiquiFlo 1.5 AC Power Modules, Hardware Reference Version 1.2
Table 2.1 – Power and Enclosure Ratings
* With V/Hz regulation, 110% continuous output current capability. With vector regulation, 150% output current capability for 5 sec.
**Note that LiquiFlo 1.5 drives are rated for use with water at specified temperatures and pressures as the coolant. Some coolant fluids
may allow an increased output rating while others may require the output to be derated. The LiquiFlo 1.5 drive is also capable of running
at 4 kHz or 8 kHz. Contact Reliance Electric for ratings.
2.2
Enclosure Ratings
LiquiFlo 1.5 drives have the following enclosure rating:
•
Open-Chassis Style: Intended to be installed in an enclosure.
LiquiFlo 1.5 drives must be placed in an enclosure.
2.3
B-Frame LiquiFlo 1.5 Drive Component Locations
The B-Frame LiquiFlo 1.5 drives have the following main components. The numbered
items listed below provided correspond to the numbers used in figure 2.2.
Replacement parts are listed in chapter 9.
Model
Number
Frame Size and
Selected
Regulation*
Enclosure
Rating
Input
Power
(KVA)
Input
Current
(Amps)
Output Current
at 2 kHz**
(Amps)
Full Load
Power Loss Watts
Fluid / Air
LF150414R4
LF150414W4
B-Frame
V/Hz or Vector
Open-Chassis
Style
344
414
414
4600 / 1100
LF150500R4
LF150500W4
C-Frame
V/Hz or Vector
Open-Chassis
Style
398
500
500
5500 / 1500
LF150643R4
LF150643W4
C-Frame
V/Hz or Vector
Open-Chassis
Style
512
643
643
7000 / 2000
LF151200R4
LF151200W4
D-Frame
V/Hz or Vector
Open-Chassis
Style
956
1200
1200
11700/4000
1.
Bus Bars (3) (AC Output)
2.
Bus Bars (6) (AC Input)
3.
IGBT Modules
4.
Output Laminate
5.
Capacitors
6.
DPI Communication Interface Board
7.
Optional Communication Board (RS485 shown)
8.
Casting
9.
AC Line I/O Board
10. Inlet Coolant Line
11. Control Board
12. Power Interface Control (PIC) Board
13. Outlet Coolant Line
14. Current Feedback Devices (3)
