Rockwell Automation 1440-REX00-04RD XM-441 Expansion Relay Module User Manual
Page 30

Rockwell Automation Publication GMSI10-UM019C-EN-P - June 2011
30 Specifications
Power
Module
Consumption
Heat Production
24V DC
120mA maximum
2.9 Watts (9.9 BTU/hr) maximum
Environmental
Operating Temperature
Storage Temperature
Relative Humidity
-20 to +65°C (-4 to +149°F)
-40 to +85°C (-40 to +185°F)
95% non-condensing
All printed circuit boards are conformally coated
in accordance with IPC-A-610C,
Physical
Dimensions
Terminal Screw Torque
Height: 3.8in (97mm)
Width: 3.7in (94mm)
Depth: 3.7in (94mm)
7 pound-inches (0.6Nm)
Approvals
(when product or packaging is marked)
* See the Product Certification link at
www.rockwellautomation.com for
Declarations of Conformity, Certificates and
other certification details.
XM-441 Technical Specifications
Product Feature
Specification
UL
UL Listed for Ordinary
Locations
UL
UL Listed for Class I, Division 2
Group A, B, C, and D Hazardous
Locations
CSA
CSA Certified Process Control
Equipment
CSA
CSA Certified Process Control
Equipment for Class I, Division
2 Group A, B, C, and D
Hazardous Locations
EEX*
European Union 94/9/EEC ATEX
Directive, compliant with EN
50021; Potentially Explosive
Atmospheres, Protection “n”
CE*
European Union 89/336/EEC
EMC Directive
C-Tick*
Australian
Radiocommunications Act,
compliant with:
AS/NZS 2064, Industrial
Emissions
