Appendix
A
Specifications
The Appendix lists the technical specifications for the XM-441 module.
XM-441 Technical Specifications
Product Feature Specification
Communications
Side Connector
Communication interface is via the side
connector between the XM-441 and the XM
module mounted directly to the left of the
XM-441.
All XM measurement and relay modules
include side connectors that allow
interconnecting adjacent modules, thereby
simplifying the external wiring
requirements.
The interconnect provides primary power,
DeviceNet communication, and the circuits
necessary to support expansion modules,
such as the XM-441 Expansion Relay
module.
NOTE: DeviceNet protocol, which is not used by
the XM-441, and primary power are passed
through the module’s terminal base to modules
connected on either side of the XM-441.
Indicators
5 LEDs Module Power -green
Relay 1 - red
Relay 2 - red
Relay 3 - red
Relay 4 - red
Relays
Number
Contacts
Failsafe
These features are managed/controlled by
the host XM module. Refer to the applicable
XM module’s specification for details on
these features:
Four relays, two sets of contacts each -
DPDT (2 Form C)
250V AC, 50/60 Hz, 3 A Resistive
Normally energized (failsafe), or
Normally de-energized (non-failsafe)
Latching
Time Delay
Voting Logic
Reset
Activation
