Rockwell Automation Publication GMSI10-IN001A-EN-P - May 2013
Enwatch Unit 19
Bias voltage reading When you define a process measurement of DC in the Emonitor software, the Enwatch unit reads the transducer bias
voltage.
24V means open circuit, 10V is OK.
Maximum number of averages that can be supported Number of samples required: Lines x 2.56 + lines x 2.56(#avg -1) x (1 -%overlap)
Max number of samples per configuration: 32768
Max number of averages = ((32768 / (lines x 2.56)) - 1) / (1 -%overlap) + 1)
The following table shows the maximum number of averages versus the number of lines and percent overlap for non-trigger
point.
The following table shows the maximum number of averages versus the number of lines and percent overlap for pre-trigger
point.
Signal detection RMS, Peak, Peak-Peak
Configuration downloading Route mode configuration downloads to Flash memory
Live mode configuration downloads to RAM
Note: You can reduce number of average or increase percent overlap to reduce amount of memory used.
Table 2 - Enwatch measurement capabilities
Product Feature Capability
Max samples-non trigger points 32768
% overlapping % overlapping % overlapping % overlapping
#lines 0 0.25 0.5 0.75
100 128 170 255 509
200 64 85 127 253
400 32 42 63 125
800 16 21 31 61
1600 8 10 15 29
3200 4 5 7 13
6400 2 2 3 5
12800 1 1 1 1
Max samples-trigger points 16384
% overlapping % overlapping % overlapping % overlapping
#lines 0 0.25 0.5 0.75
100 64 85 127 253
200 32 42 63 125
400 16 21 31 61
800 8 10 15 29
1600 4 5 7 13
3200 2 2 3 5
6400 1 1 1 1
12800 - - - -
