1-4 High Power SA3000 AC Power Modules
1.4 Related Publications
This manual describes the hardware components of the SA3000 Inverter Power
Module. The other instruction manuals in binder S-3001 describe the SA3000
software, regulator, and communications. Table 1.1 lists the document part numbers.
SA3000 Power Modules are designed to be operated from a common DC bus, which
can be supplied by a Distributed Power System SB3000 Synchronous Rectifier. Refer
to the following manuals for information on the SB3000 Synchronous Rectifier system:
• S-3034 SB3000 Synchronous Rectifier Configuration and Programming
• S-3043 High Power SB3000 Power Modules
1.5 Related Hardware and Software
The following related hardware may be purchased separately:
• P/N 613613-xxS Fiber-optic cable (cable length xx is specified in meters)
• B/M O-57552 Universal Drive Controller (UDC) module
• B/M O-57652 Universal Drive Controller (UDC) module EM
Table 1.2 – SA3000 Documentation (Binder S-3001)
Document Document Part Number
SA3000 Information Guide S-3023
Drive System Overview S-3005
Universal Drive Controller Module S-3007
Fiber Optic Cabling S-3009
SA3000 Drive Configuration & Programming S-3016
SA3000 Power Module Interface Rack and Modules S-3019
Medium Power SA3000 Power Modules S-3020
SA300 Diagnostics, Troubleshooting, & Start-Up
Guidelines S-3021
High Power SA3000 Power Modules S-3038
