Installation 2-19
Grade 12.9 – ISO 898/1 Socket Head Cap Bolts (ANSI B1.13M, ISO 261,
ISO 262 [coarse series only]) All bolts must meet the specified grade or better.
Microsize Bolt
To convert inch-pounds to inch-ounces, multiply by 16.
To convert inch-pounds to foot-pounds, divide by 12.
Electrical Wiring/Interface
Specifications
Table 2.O Recommended Seating Torques (Inch-Lb.) for Metric Bolts
Bolt Size
(Metric) Pitch Plain Cadmium
Plated Zinc
M1.6 0.35 2.6 1.95 3.64
M2 0.40 5.3 3.98 7.42
M2.5 0.45 11 8.25 15.4
M3 0.5 19 14.25 26.6
M4 0.7 41 30.75 57.4
M5 0.8 85 63.75 119
M6 1.0 140 105 196
M8 1.25 350 262.5 490
M10 1.5 680 510 1020
Table 2.P Motor Power Cable
Standard Wiring Color from Motor Designation Comments
Red Motor Phase U (A)
• Observe
maximum
applied voltage
specification.
• Consult drive
manual or
supplier for
specific wiring
instructions to
the drive. Wiring
is phase/
commutation
sensitive.
White Motor Phase V (B)
Black Motor Phase W (C)
Green Motor Ground Terminate per drive
manual instructions.
Shield is not
connected to the
motor frame.
Shield Cable Shield
