LD-Series Motor Installation Instructions 9
Publication LD-IN001A-EN-P — September 2000
Dimension Symbol
1
(Refer to drawing)
Motor
LD-2003 LD-3009 LD-4012 LD-4030
AB mm 38 50 55 55
(in.) (1.5) (1.97) (2.16) (2.16)
AF mm 20 25 30 30
(in.) (0.78) (0.98) (1.18) (1.18)
AH mm 24 30 35 35
(in.) (0.94) (1.18) (1.38) (1.38)
AJ mm 60 90 100 100
(in.) (2.36) (3.54) (3.94) (3.94)
AK mm 50 70 80 80
(in.) (1.97) (2.76) (3.15) (3.15)
BB mm 2.5 3.0 3.0 3.0
(in.) (0.10) (0.12) (0.12) (0.12)
BE mm 5 8 8 8
(in.) (0.2) (0.31) (0.31) (0.31)
BF mm 4.5 5.5 6.6 6.6
(in.) (0.18) (0.22) (0.26) (0.26)
EP mm 12 16 19 19
(in.) (0.47) (0.63) (0.75) (0.75)
L mm 86 103 116 172
(in.) (3.38) (4.05) (4.57) (6.77)
L with Brake mm 115 130 156 212
(in.) (4.53) (5.12) (6.14) (8.35)
P mm 54 76 86 86
(in.) (2.13) (2.99) (3.39) (3.39)
S mm 3 x 3 5 x 5 5 x 5 5 x 5
(in.) (0.12 x 0.12) (0.2 x 0.2) (0.2 x 0.2) (0.2 x 0.2)
U mm 8 14 16 16
(in.) (0.31) (0.55) (0.63) (0.63)
XD mm 12 20 25 25
(in.) (0.47) (0.79) (0.99) (0.99)
XE mm 2 2 2 2
(in.) (0.08) (0.08) (0.08) (0.08)
1
LD-Series motors are designed to metric dimensions. Imperial measurements are mathematical conversions.
