Mounting dimensions – Rockwell Automation LD-Series Brushless Servo Motor User Manual
Page 8
8
LD-Series Motor Installation Instructions
Publication LD-IN001A-EN-P — September 2000
Mounting Dimensions
The dimension symbols and actual dimensions of the different models in
the LD-Series are referenced in a table on the next page.
Figure 1
Reference for Mounting Dimensions
L
AH
BE
BB
AF
XE
Cable length for all motors:
1000 mm (39.37 in.)
XD
S
U
EP
AB
P
AK
BF = DIA. HOLES
AJ = DIA. BOLT CIRCLE
L
