12 LD-Series Motor Installation Instructions
Publication LD-IN001A-EN-P — September 2000
Cables and Connector Kits
Factory manufactured cables are available in standard cable lengths. They
can provide environmental sealing and shield termination. The following
cables are for connecting the LD-Series motors.
Catalog Number Description
9101-1375-XXX
1 Cable, Encoder Feedback to
ULTRA 100 or ULTRA 200 Drive
(with encoder and drive mating connectors)
9101-1385-XXX
1 Cable, Motor Power to Drive
(with motor connector and pigtail to drive
terminals)
9101-1786-XXX
2 Cable, Encoder Feedback to
Ultra3000 or Ultra5000 Drive
(with encoder and 45° drive mating
connector)
9106-0066 Connector Kit
(kit includes connector, pins and backshell for
both the power and encoder connectors)
1 The last three digits (XXX) indicate a standard cable length:
010 = 3 m (10 ft)
025 = 7 m (25 ft)
050 = 15 m (50 ft)
075 = 23 m (75 ft)
2 The last three digits (XXX) indicate a standard cable length:
001 = 1 m (3.3 ft)
003 = 3 m (10 ft)
009 = 9 m (30 ft)
015 = 15 m (50 ft)
030 = 30 m (100 ft)
