Reliance electric – Rockwell Automation MinPak Plus Local Operator Station Faceplate Kit 14C201-208 User Manual
Page 4
CIRCUIT
BREAKER
BOOT
PLATE
INSTALLED
Figure 5 - Three Phase MinPak Plus Operators
Control Station Installed
Figure 6 - Local Faceplate Connectors
LOCAL
OPERATOR'S
CONTROL
CONNECTS
HERE
J9
J8
J4
J10
Figure 7 - Three Phase MinPak Plus Regulator Board Jumper Location
Reliance Electric Company / 24703 Euclid Avenue / Cleveland, Ohio 44117
RELIANCE ELECTRIC
Printed in U.S.A.
DĆ3977
8821.5M
