INSTRUCTION MANUAL DĆ3977
ACCESSORY
LOCAL OPERATOR STATION FACEPLATE KIT
MODEL NUMBERS14C201 THRU 14C208
The equipment described below should be installed only by qualified electrical maintenance personnel
familiar with the construction and operation of the equipment and the hazards involved.
DANGER
CONTROLLER EQUIPMENT ISAT LINE VOLTĆ
AGE WHEN AĆC POWER ISCONNECTED TO
THE POWER UNIT IN THE MINPAK PLUSCONĆ
TROLLER. THUS, AĆC POWER MUST BE REĆ
MOVED FROM THE UNIT BEFORE IT ISSAFE
TO TOUCH INTERNAL PARTSOF THE CONĆ
TROLLER. PERSONAL INJURY MAY RESULT
UNLESS POWER IS REMOVED.
DESCRIPTION
For proper operation of the Three Phase MinPak Plus,
it is necessary to use an Operator's Control Station.
When the station is mounted locally on the cabinet door,
users may select from eight (8) Standard Faceplates
(Model No. 14C201 thru 14C208) in order to configure
a controller to a specific drive application. Table 1.A is
an inclusive listing of Faceplate types, Model Numbers
and functions. With the local Operator's Station FaceĆ
plate properly installed, the Controller will maintain the
NEMA Type 12 rating.
The Faceplates are supplied with a bag of 8 hex nuts. No
other equipment nor any other Reliance options are reĆ
quired with this option.
If a Local Operator Station contains an AUTO/MANUAL
switch, it is necessary to remove jumper J4 from the
Regulator Module. (Refer to Figure 7).
LOCAL
OPERATOR
CONTROL
STATION
Figure 1 - MinPak Plus W/Local Operator
Control Station Faceplate
