Kinetix 6000M Integrated Drive-Motor 11
Rockwell Automation Publication MDF-IN001B-EN-P - August 2013
Product Dimensions
Refer to the tables on
for the physical dimensions shown in this figure.
D
L- LB
LD
LE
2.74
(0.108)
LB
LA
G
F
HD
P1
63.6
(2.50)
AD
42.3
(1.66)
N
MDF-SB1003 = 2.87 (0.113)
MDF-SB1153 = 2.87 (0.113)
± 0.83 (0.032)
MDF-SB1304 = 3.38 (0.133)
± 0.83 (0.032)
P1
P
2.74 (0.108)
L
± 0.83 (0.032)
Reinforcing Boss Extension on Front Faceplate
MDF-SB1003 = 2.5 (0.10)
MDF-SB1304 = 1.65 (0.07)
MDF-SB11153 = 2.0 (0.08)
Shaft Detail with Key
Detail A
Wear Collar / Shaft Shoulder
Flush to Pilot
Pilot Relief Ø
Use shaft end mark or shaft key to orient
encoder absolute position (0° ±10°).
S on M
S = Diameter of Mounting Holes
M = Diameter of Bolt Circle
MDF-SB1003P-Qx82B-S motor shown
See Detail A
Connector housing can be rotated
one-time within a range of 180°.
Pilot Height
Pilot Ø
Shaft End Threaded Hole
MDF-SB1003 IDM Units
Thread - M5 x 0.8-6H
Thread Depth - 12.5 (0.49)
MDF-SB1153 IDM Units
Thread - M6 x 1.0-6H
Thread Depth - 16 (0.63)
MDF-SB1304 IDM Units
Thread - M8 x 1.25-6H
Thread Depth - 19 (0.75)
Shaft Seal
Refer to
for Kinetix 6000M
Integrated Drive-Motor
shaft seal kit information.
MDF-SB1003 = 5 x 5 x 22 Key
MDF-SB1003 = 6 x 6 x 24 Key
MDF-SB1003 = 8 x 7 x 31 Key
Pilot Relief Diameter
MDF-SB1003 = 53.3 (2.10)
MDF-SB1153 = 59.7 (2.35)
MDF-SB1304 = 71.1 (2.80)
