A-2 SB3000 Power Modules (RCS)
• Maximum AC Line Variation: +/- 10%
• AC Line Frequency: 25, 50, and 60 Hz, +/- 2 Hz
• Frequency Rate of Change: 1Hz/sec
• Maximum AC Line Current: 534A, 972A, 1457A
• Maximum Phase Imbalance: 5%
AC Control Power
• AC Input Voltage: 115 VAC
• AC Input Frequency: 50/60 Hz
DC Output Power
• Minimum Output Voltage: 1.414 x VAC x 1.1 x 1.1
• Maximum Output Voltage: 900V
• Output Voltage Regulation: +/- 1%
• Maximum DC Output Current: (1.70 x E
Line
x I
Line
x Power Factor) / VDC
• Maximum Short Circuit Current: 100KA
• Output Voltage Resolution: 0.5V
• Output Voltage Regulation: Less than 5% for +/- 100% current step change
• Voltage Regulator Response: 100 rad/sec.
• VAR/Power Factor Correction:
The user can select the maximum amount of SB3000 VAR correction. The SB3000
Power Module will always give the voltage regulator priority over the VAR function. If
the output of the SB3000 is less than its limit, it will attempt to produce VARs up to
the limit set by the user. Refer to Appendix B, section B.2.1.
SB3000 Power Module Current Ratings
1
SB3000 Part Number
Continuous
AC Input Current
(460VAC)
Continuous
DC Output Current
(800VDC)
5 Minute
AC Input and DC Output
Overload 2
850021 – 21xxx, 31xxx 445A (rms) 445A DC 534A (rms)
850021 – 22xxx, 32xxx 890A (rms) 890A DC 972A (rms)
850021 – 23xxx, 33xxx 1,335A (rms) 1,335A DC 1,457A (rms)
1. At 460 VAC Input/800 VDC Output/4 kHz Carrier Frequency. For use with SA3000 Power Modules operating at a 2 kHz carrier
frequency.
2. With a 25% duty cycle
