Trusted
TM
Module T8480
Issue 13 Apr 10 PD-T8480 20
OEM Parameter Description Notes
TICS_CHASSIS The number of the
Trusted TM Chassis where
the Primary I/O module is
installed
The Trusted TM Controller Chassis is 1, and
Trusted TM Expander Chassis are 2 to 15
TICS_SLOT The slot number in the
chassis where the Primary
I/O module is installed The I/O module slots in the Trusted TM Controller
chassis are numbered from 1 to 8. The I/O
Module slots in the Trusted
TM Expander Chassis
are numbered from 1 to 12
Table 4 OEM Parameters
3.2.1. Rack 1: AO
This board provides the connection to the logical output control signal for each of the field outputs.
Channel Description
1 Field output channel 1 command
2 Field output channel 2 command
40 Field output channel 40 command
Table 5 Rack 1: AO descriptions
The output command scaling is designed to be consistent with the T8431 Analogue Input module.
This relationship is described by the table below:
Command Output Current
-1024 Off (Minimum leakage current flowing)
0 4 mA
4096 20 mA
Table 6 Rack 1: Output Current descriptions
3.2.2. Rack 2: State
This board provides the majority voted numerical output state. This indicates the operational status of
the output channel and associated field connection.
Channel Description
1 Field output channel 1 state
2 Field output channel 2 state
40 Field output channel 40 state
Table 7 Rack 2: STATE descriptions
