Page 62: Chapter

Chapter
5
Publication 2755-6.4
Communication Setup (Synapse
Cable)
This chapter describes how to configure scanner communication
parameters. The types of options available depends on the synapse
cable you are using.
For This Cable:
See These Pages:
RS-232 Synapse Cables
5–2 through 5–8
IBM PC Keyboard Wedge Synapse Cables
5–9 through 5–12
DEC VT520 Keyboard Wedge Synapse Cable
5–13 through 5–15
DEC VT220, VT320, VT420 Keyboard Wedge Synapse Cable
5–16 through 5–18
Scanner Emulation Synapse Cable
5–19 through 5–23
Important: All programming codes are located in the
Programming Guide for 2-D Bar Code Scanners (Publication
2755-6.7).
Cable Defaults
To set cable defaults, scan the default label for the synapse cable you
are using. Refer to each cable section for a table listing the defaults.
The selections for cable defaults are:
•
Set RS-232 Synapse Cable Defaults
•
Set IBM PC Keyboard Wedge Synapse Cable Defaults
•
Set DEC VT 520 Keyboard Wedge Synapse Cable Defaults
•
Set DEC VT VT220, VT320, VT420 Wedge Synapse Cable
Defaults
