Déconnexion du terminal, Retrait du terminal existant – Rockwell Automation 2711P-xxxx Adapter Kit for PanelView Std and e Terminals User Manual
Page 11
Kit d’adaptation pour découpe de terminal PanelView Standard et PanelView « e » 11
Publication 2711P-IN010C-MU-P - March 2007
Déconnexion du terminal
1. Déconnectez l’alimentation à la source et débranchez le cordon
d’alimentation du terminal PanelView.
2. Déconnectez tous les câbles de communication du terminal.
Retrait du terminal existant
1. Retirez les colliers de fixation qui maintiennent le terminal sur le panneau.
2. Retirez le terminal du panneau.
ATTENTION
Assurez-vous que le cordon d’alimentation du terminal PanelView est
déconnecté et que tous les autres câbles sont déconnectés du terminal.
TIP
Les colliers de fixation des PanelView Standard/ PanelView « e » sont
différents des colliers des PanelView Plus. Rangez les colliers séparément pour
éviter toute erreur par la suite.
