6185-c monitor hazardous locations, Power indicators – Rockwell Automation 6185-C_B Industrial 15 12 Inch Monitor User Manual User Manual
Page 9

6185-C and 6185-B Industrial Flat Panel Monitors
9
Publication 6185-5.1
See the nameplate label on the 6185-C monitor for certifications.
ATTENTION: In Class I, Division 2 hazardous
locations, the panel mount (6185-C) must be wired per
the National Electric Code and/or Canadian Electric code
as it applies to hazardous locations.
A bi-color LED is provided on the front panel to indicate various
operating modes. The following table describes the functions assigned to
each color.
Table B
Power Indicator LED
LED Color
Indication
Green (solid)
Power ON, video sync detected (normal operation)
Amber (solid)
Power ON, loss of video sync or disconnected video
cable
Optional Full Range Dimming is available on 6185-C models. If your
monitor has this option, you will have two LEDs. For more details on
using the Full Range Dimming functionality and reading the LEDs, see
Adjusting the Full Range Dimming Control on page 30.
6185-C Monitor
Hazardous Locations
Power Indicators
