1 Publication 4100-IN054B-EN-P - January 2001
Appendix
A
Accessories
Principle Accessories This section lists the principle accessories available for use with this
product. It includes cables for connecting the Encoder Buffer Unit to
Master Encoders and other devices.
Table 0.A Principle Accessories
Crimped flying leads to 15 way high density D socket.
Supplied with loose 12 way AMP connector shell which
can be used for 1394 or ALEC. User connection drawing
for 1394 & ALEC included. Red and Black wires for the
1394 5V encoder supply included. Crewe Part number 44-0268-XXX
Crewe Description 8 or 4 Channel Buffer to 1394 or
ALEC
Passport No. 4100-EFCCXXX
Passport Description Encoder Fanout Board to 1394
cable
Un-crimped flying leads to 15 way high density D plug
compatible with EF08/04 Master socket. Allows
customers to connect non-standard encoder to EFO08/4.
Data sheet defining pin-out and color included. Has
encoder power connected to pin 9. Crewe Part number 44-0269-XXX
Crewe Description Flying lead to 8/4 Channel Buffer
I/P
Passport No 4100-EFCEXXX
Passport Description Encoder Fanout Board to Encoder
Flying leads.
MIL spec 10way (18-1) socket to 15 way high density D
plug compatible with EF08/04 Master socket. Connects
845 encoder (or equivalent) to EF08/04. Has encoder
power connected to pin 9. Crewe Part number 44-0192-XXX
Crewe Description 5V & 12V encoder to 8/4 Channel
Buffer I/P
Passport No. N/A
Passport Description N/A
Fitted 12 way AMP connector to 15 way high density D
socket. Dedicated for 1394 only and supplied with user
sheet for external 5V connection. Crewe Part number 44-0254-XXX
Crewe Description 8/4 Channel Follower to 1394 only
Passport No. N/A
Passport Description N/A
