8 way encoder buffer unit mechanical drawing, 4 way encoder buffer unit mechanical drawing, 77 mm – Rockwell Automation 4100-EF04_EF08 4 or 8 Way Encoder Buffer Unit Installation and Setup Manual User Manual
Page 16: Figure 1.1 8 way encoder buffer unit, Figure 1.2 4 way encoder buffer unit, 295 mm max
Publication 4100-IN054B-EN-P - January 2001
1-4 Overview
8 Way Encoder Buffer Unit Mechanical Drawing
(Part Number 4100-EF08 series B)
Figure 1.1 8 Way Encoder Buffer Unit
4 Way Encoder Buffer Unit Mechanical Drawing
(Part Number 4100-EF04 series B)
Figure 1.2 4 Way Encoder Buffer Unit
430 mm MAX
77 mm
8 Channel Encoder Buffer
HEALTHY
P1
P2
P3
P4
P5
P6
P7
P8
P9
P10
FLWR-1
MASTER
FLWR-2
FLWR-3
FLWR-4
FLWR-5
FLWR-6
FLWR-7
FLWR-8
ENCODER DIRECTION
LK-DIR
LK-VOLTS
ENC VOLTAGE
FOLLOWER POWER LK-5V-FX
+12V +5V
LK-5V-F4
LK-5V-F1
LK-5V-F2
LK-5V-F3
LK-5V-F5
LK-5V-F6
LK-5V-F7
LK-5V-F8
295 mm MAX
77 mm
4 Channel Encoder Buffer
+12V +5V
HEALTHY
P1
P2
P3
P4
P5
P6
MASTER
FLWR-1
FLWR-2
FLWR-3
FLWR-4
LK-Volts ENC VOLTAGE
LK-DIR
ENCODER DIRECTION
LK-5V-F1
LK-5V-F2
LK-5V-F3
LK-5V-F4
FOLLOWER POWER LK-5V-FX
