34 DeviceNet Serial Interface Module
Publication 1799-IN012B-EN-P - July 2008
Environmental Specifications
Attribute Value
Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20…70
°
C (-4…158
°
F)
Temperature, nonoperating IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, U npackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock):
-40…85
°
C (-40…185
°
F)
Relative humidity IEC 60068-2-30 (Test Db, Unpackaged Nonoperating Damp Heat):
5…95% noncondensing
Shock, operating IEC 60068-2-27 (Test Ea, Unpackaged Shock)
30 g peak acceleration
Shock, nonoperating IEC 60068-2-27 (Test Ea, Unpackaged Shock)
50 g peak acceleration
Vibration IEC 60068-2-6 (Test Fc, Operating)
5 g @ 10…500 Hz
ESD immunity IEC 61000-4-2:
8 kV indirect contact discharges
Radiated RF immunity IEC 61000-4-3:
10V/m with 1 kHz sine-wave 80%AM from 30…2000 MHz
10V/m with 200 Hz 50% Pulse 100%AM at 900 MHz
10V/m with 200 Hz 50% Pulse 100%AM at 1890 MHz
3V/m with 1 kHz sine-wave 80%AM from 2000…2700 MHz
EFT/B immunity IEC 61000-4-4:
+2 kV at 5 kHz on communication ports
Surge transient immunity IEC 61000-4-5:
+2 kV line-earth (CM) on shielded ports
Conducted RF immunity IEC 61000-4-6:
10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz
Emissions CISPR 11
Group 1, Class A
Wire Size
0.25...2.5 mm
2
(22...14 AWG) solid or stranded shielded copper wire
rated at 80 °C (176 °F) or higher. Refer to DeviceNet Media Design And
Installation Guide, publication DNET-UM072.
Wiring category
(1) 2 - on communication ports
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and
Grounding Guidelines, publication 1770-4.1.
