DeviceNet Serial Interface Module 33
Publication 1799-IN012B-EN-P - July 2008
Specifications
DeviceNet Serial Interface Module- 1799-DASCII
Attribute
Value
Description
Communication gateway between a serial-capable device over an RS-232 or RS-485
interface and a DeviceNet network
Device type
Rockwell Miscellaneous, 115, 0x73 hex
Product code
220, 0xDChex
Vendor ID
Allen-Bradley/Rockwell Automation
Device profile
Identity Object 0x01
Message Router Object 0x02
DeviceNet Object 0x03
Assembly Object 0x04
Connection Object 0x05
Parameter Object 0x0F
Acknowledge Handler 0x2B
Serial I/O Object 112, 0x70 (vendor-specific)
Transmit Serial Object 113, 0x71 (vendor-specific)
Receive Serial Object 114, 0x72 (vendor-specific)
Product revision
1.01
DeviceNet
Baud rate: autobaud operation and software selection
Address selection: address number 0…63 with rotary switches
DeviceNet connection: 5-pin open connector
Serial port
RS-232 and RS-485
Baud rate: 1200, 2400, 4800, 9600, 19.2 k, 38.4 k, 57.6 k, 115.2 k
Parity: odd/even/none
Connector: - pin D-shell, 9-pin male D-shell
Indicators
DeviceNet network:
Module status - red/green
Network status - red/green
Serial port:
Transmit active - green
Receive active - green
Isolation voltage
50V (continuous), Basic Insulation Type
Type tested at 1500V DC for 60 s, DeviceNet network to Serial, and Logic to
Communication ports
Power
1.8 W: 75 mA @ 24V DC max
Enclosure type rating
None (open-style)
Weight, approx.
34.6 g (1.22 oz)
