Kinetix 6000 Power Rail 3

Publication 2094-IN003D-EN-P - November 2010

Catalog Number Explanation

This publication applies to the following Bulletin 2094 power rails.

Before You Begin

Remove all packing material, wedges, and braces from within and around the components. After
unpacking, check the item nameplate catalog number against the purchase order.

Parts List

Cat. No.

Description

Module Capacity

(1)

(1)

Module capacity is reduced when using double-wide IAM and AM modules. The 2094-AC32-M05-x, 2094-BC04-M03-x, and
2094-BC07-M05-x double-wide IAM modules each require one converter slot and two inverter slots. All other (single-wide)
IAM modules require one converter slot and one inverter slot. The 2094-BM03-x and 2094-BM05-x double-wide AM
modules each require two inverter slots. All other (single-wide) AM modules require one inverter slot. Refer to the Kinetix
Motion Control Selection Guide, publication

GMC-SG001

, for more information on selecting Bulletin 2094 power rails.

2094-PRS1

Power rail (slim),
230V or 460V drive systems

1 IAM module and no additional modules

2094-PRS2

1 IAM module and up to 1 additional module

2094-PRS3

1 IAM module and up to 2 additional modules

2094-PRS4

1 IAM module and up to 3 additional modules

2094-PRS5

1 IAM module and up to 4 additional modules

2094-PRS6

1 IAM module and up to 5 additional modules

2094-PRS7

1 IAM module and up to 6 additional modules

2094-PRS8

1 IAM module and up to 7 additional modules

2094-PR1

Power rail,
230V or 460V drive systems

1 IAM module and no additional modules

2094-PR2

1 IAM module and up to 1 additional module

2094-PR4

1 IAM module and up to 3 additional modules

2094-PR6

1 IAM module and up to 5 additional modules

2094-PR8

1 IAM module and up to 7 additional modules

Drive Component

Ships With

Power Rail

One braided 100 mm (3.9 in.) ground strap

Protective covers (one covering each of the power rail connectors)

These installation instructions, publication 2094-IN003

IMPORTANT

To improve the bond between the power rail and subpanel, construct your
subpanel out of zinc plated (paint free) steel.
