2 Chapter
2–1
Installing the Software
This chapter describes how to load the DL5 Off-line Programmer into your
personal computer.
The Off-line Programmer is software for programming DL5 Message
Displays. Using the Off-line Programmer is an efficient way to program
several DL5s with the same message set. The DL5 messages are created
using a personal computer and then downloaded to the display. You can also
receive (upload) messages from a DL5 that has already been programmed.
This software is menu driven with a new screen for each programming step.
It can be used with the following systems:
•
Allen-Bradley 1784-T45, -T47, -T50, and -T60 Industrial Computers
•
Allen-Bradley 6120 and 6121 Industrial Computers
•
Most IBM PC AT and XT or compatible computers
Off-line programming software is supplied on both a 5 1 /
4
inch floppy disk
and a 3 1 /
2
inch micro disk. Be sure you have the disk that fits your system.
Use this guide to get acquainted with the interactive programming software
to create and maintain your own library of DL5 message display programs.
This section shows you the procedure for installing the DL5 Off-line
Programmer on your computer. Read the following important information
before getting started on your system.
Important: This software is copyrighted but not copy protected. It is
recommended that you make a copy now and store the original disk in a safe
place. You will need a blank disk.
Chapter Objectives
Before You Begin
Installing DL5.EXE
