Chapter 4
Running DL5 Off-line Programmer
4–13
There are four Special Functions. See Table 3.B for Functions and Options.
Table 4.B
Display Special Functions
Special Function Option Description
High True
Parallel Port Logic
Y
N Voltages on data lines are positive logic signals.
Voltages on data lines are negative logic signals.
DL5 RS-232 Port
Baud Rate
3
1
9 DL5 Baud Rate set to 300
DL5 Baud Rate set to 1200
DL5 Baud Rate set to 9600
DL5 Run Mode
NM
PR
BN
BC
RR
Parallel port uses NUMERIC run mode
Parallel port uses PRIORITY run mode
Parallel port uses BINARY run mode
Parallel port uses BINARY CODED DECIMAL (BCD) run
mode
Parallel port uses ROUND ROBIN run mode
Autorun Message
Number
A Valid Message
Number
This message will be displayed when the DL5 goes into
Autorun Mode after power has been applied Note:
Select 0 to disable the Autorun function.
1. Define the Special Functions settings by selecting the desired option code
and then pressing [RETURN] or [ENTER]. You can move about within
the menu by using the [RETURN] key or the up [
"] and down [#] arrow
keys.
2. Press [END] to save the Special Functions and return to the Edit screen.
