Rockwell Automation 2706-P22R InView Panel Mount Message Display Installation Instructions User Manual
Page 33
Visualizzatore di messaggi InView montato a pannello 33
Pubblicazione 2706-IN014B-MU-P
Caratteri per riga
20
Distanza di visualizzazione (approx.)
7,6 metri (25 piedi)
Tipo caratteri
LED rosso
Elettriche
Tensione di ingresso
da 18 a 30V cc, 0,5A a 18V cc
Potenza di ingresso
10 Watt
Tipo fusibile
Fast Acting Littel serie 217 o equivalente 1,6 A
Comunicazione seriale
Interfaccia elettrica
RS-232 (EIA-/TIA-232-E)
RS-485 (EIA-485)
Baud Rate
9600
Ambientali
Gamma temperatura - in funzione
da 0C a +55C (da +32F a +131F)
Gamma temperatura - stoccaggio
da -20C a +85C (da -4F a +185F)
Umidità
dal 5% al 95% (senza condensa)
Urto
In funzione 15G, a riposo 30G impulsi
Vibrazioni
In funzione 2.0G
Meccaniche
Tipo custodia
Listato UL per NEMA Tipo 12, 13, 4X (solo uso interno) se
montato in una custodia adeguata di Tipo 12, 13, 4X, IP65 o
IP54
Peso - Approssimativo
0,85 kg (1,87 lbs)
