Integrated Display Computers 19
Publication 6181P-IN001I-EN-P - July 2008
Mechanical Specifications
Specification Value
Weight
1200P
1500P
1700P
9.2 kg (21 lb)
10 kg (23 lb)
12.6 kg (28 lb)
Dimensions (H x W x D), approx.
1200P
1500P
1700P
279 x 349 x 176 mm (10.99 x 13.75 x 6.93 in)
309 x 410 x 109 mm (12.17 x 16.14 x 4.29 in)
356 x 452 x 110 mm (14.02 x 17.80 x 4.32 in)
Cutout dimensions (H x W), approx.
1200P
1500P
1700P
254 x 324 mm (10.00 x 12.76 in)
285 x 386.6 mm (11.24 x 15.22 in)
329.5 x 424 mm (12.97 x 16.69 in)
Environmental Specifications
Specification Value
Temperature, operating 0…50 °C (32…122 °F)
Temperature, storage -20…60 °C (-4 to 140 °F)
Relative humidity 10%…90% without condensation
Shock, operating 15 g (1/2 sine, 11 ms) (1) (2)
Shock, nonoperating 30 g (1/2 sine, 11 ms) (1)
Vibration, operating
Computers, rotating hard drive
Computers with solid state drive
1.0 g peak (10…500 Hz) (1) (2)
1.5 g peak (10…500 Hz) (1) (2)
Vibration, nonoperating
2.0 g peak (10…500 Hz)
(1)
Enclosure ratings NEMA Type 1, 12, 4, IEC IP66
NEMA Type 4X for stainless steel units only
(1) Applies to panel-mounted products only.
(2) The floppy drive and optical disc drive are considered maintenance devices. You should not operate computers with these
devices in environments with the shock and vibration levels listed.
