Rockwell Automation 2198-DB42-F Kinetix 5500 AC Line Filters Installation Instructions User Manual
Page 6

6 Kinetix 5500 AC Line Filters
Rockwell Automation Publication 2198-IN003A-EN-P - July 2012
AC Line Filter Dimensions (catalog number 2198-DB20-F)
AC Line Filter Dimensions (catalog number 2198-DB42-F)
Ø 6.0
(0.24)
R3.0
(0.12)
8.5
(0.33)
217
(8.54)
201
(7.91)
227
(8.94)
1.2
(0.05)
93
(3.66)
115.5
(4.55)
55
(2.16)
42
(1.65)
42
(1.65)
M5
Dimensions are in mm (in.).
Ø 6.5
(0.26)
R3.3
(0.13)
9.5
(0.37)
60
(2.36)
60
(2.36)
258
(10.16)
M6
240
(9.45)
129
(5.08)
1.2
(0.05)
272
(10.71)
73
(2.87)
162
(6.38)
Dimensions are in mm (in.).
