A
RENA
P
ACKAGING
T
EMPLATE
U
SER
’
S
G
UIDE
8
• •
•
•
•
Conveyors and Flow Control
HSMART10: Accumulating Conveyors
HSMART11: Linking Two Accumulating Conveyors
HSMART12: Splitting Conveyor Flow by Count
HSMART13: Merging Conveyor Flow
HSMART14: Modeling a Surge Area or Table
HSMART15: Modeling a Secondary Line
HSMART16: Modeling Rework
Tanks and Valves
HSMART17: Simple Tank and Valve
HSMART18: Tank Farm
Fronts (Sources) and Ends (Sinks) of Lines
HSMART19: Using Palletizers to End a Line
HSMART20: Using Depalletizers to Begin a Line
HSMART21: Storage Example Using Palletizer/Depalletizer
Step 2
•
Define equipment behavior
The next step is to specify the basic run parameters (e.g., run speeds), characteristics (e.g.,
reliability, loss), and dimensions (e.g., length, width, capacity) for each individual element
in the line. For example, you might have collected and organized data about the equip-
ment in your line as follows.
Processing Elements:
Element Name
Nom. Run Speed
(units/min)
Unit Loss
Reliability
for a Week
Cleaner
500
.01%
.97
Filler
650
.01%
.99
Inspector
500
1.0%
.98
Depalletizer
600
.01%
.99
