2 • G ENERAL C ONCEPTS
7
•
•
•
• •
2 • Gene
ral
Conce
pts
Once you have flowcharted your process, duplicate that flowchart in Arena by graphically
placing and connecting appropriate modules from the Packaging panel into an Arena
model window. To select a module, you simply drag and drop an icon in the panel onto the
workspace region where you want the module to be placed.
HSMARTs are a collection of small models that illustrate modeling techniques. To learn
combinations of Packaging modules that are appropriate for specific situations, it is useful
to refer to the HSMART examples for Step 1.
„
Step 1 • Place and Connect Equipment
„
Processing
„
HSMART01: Basic Processing Operation
„
HSMART02: Basic Processing Operation Using a Non-accumulating
Conveyor
„
HSMART03: Assembly Operation
„
HSMART04: Packing Operation
„
HSMART05: Filling Operation
„
HSMART06: Inspection Operation
„
HSMART07: Linking Two Machines
„
HSMART08: Modeling a Supply Constraint for an Operation
„
HSMART09: Modeling a Machine as Two or More Separate Components
