Micro800 4-channel and 8-channel Analog Voltage/current Input and Output Modules 11

Publication 2085-IN006A-EN-P - September 2012

Output Specifications – 2085-OF4

Attribute

2085-OF4

Number of Inputs

4

Resolution
Voltage
Current

12 bits unipolar; 11 bits plus sign bipolar
2.56 mV/cnt unipolar; 5.13 mV/cnt bipolar
5.13

μ

A/cnt

Data format

Left justified, 16 bit 2s complement

Step response time up to 63%

2 ms

Conversion rate, max

2 ms per channel

Output current terminal,
user configurable

0 mA output until module is configured
4…20 mA (default)
0…20 mA

Input voltage terminal,
user configurable

±

10V

0…10V

Current load on voltage output,
max

3 mA

Absolute accuracy
Voltage terminal
Current terminal

0.133 % Full Scale @ 25

°

C or better

0.425 % Full Scale @ 25

°

C or better

Accuracy drift with temp

Voltage terminal – 0.0045 % Full Scale/

°

C

Current terminal – 0.0069 % Full Scale/

°

C

Resistive load on mA output

15…500 ohm @ 24V DC

Environmental Specifications

Attribute

Value

Temperature, operating

IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20…65 °C (-4…149 °F)

Temperature, surrounding air, max

65 °C (149 °F)

Temperature, non-operating

IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock):
-40…85 °C (-40…185 °F)

Relative humidity

IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5…95% non-condensing

Vibration

IEC 60068-2-6 (Test Fc, Operating):
2 g @ 10…500 Hz

Shock, operating

IEC 60068-2-27 (Test Ea, Unpackaged Shock):
25 g

Shock, non-operating

IEC 60068-2-27 (Test Ea, Unpackaged Shock):
25 g – for DIN rail mount
35 g – for panel mount

Emissions

CISPR 11
Group 1, Class A
