Page 7: Diagrama do cabo
7
Cabo Ethernet Cruzado
Português
2711P-CBL-EX04
Aplicação
Uso os cabos de comunicação para conectar diretamente dois dispositivos Ethernet
sem um hub ou switch Ethernet. Não utilize este cabo ao conectar a um hub ou
switch Ethernet.
•
4,3 metros (14 pés)
•
Classe 5E
Diagrama do Cabo
O cabo tem dois conectores RJ45.
Pinagens do Cabo Ethernet Cruzado RJ-45 a RJ-45
Pino
RJ-45
Sinal
Direção
Pino
RJ-45
Sinal
1
TX+
→
3
RX+
2
TX+
→
6
RX+
3
RX+
←
1
TX+
4
Não Utilizado
–
4
Não Utilizado
5
Não Utilizado
–
5
Não Utilizado
6
RX-
←
2
TX-
7
Não Utilizado
–
7
Não Utilizado
8
Não Utilizado
–
8
Não Utilizado
