Deutsch, Ethernet-crossover-kabel, Anwendung – Rockwell Automation 2711P-CBL-EX04 Ethernet Crossover Cable Install User Manual
Page 4: Pinbelegung der kabelstecker
4
Ethernet-Crossover-Kabel
Deutsch
2711P-CBL-EX04
Anwendung
Verwenden Sie das Kommunikationskabel, um zwei Ethernet-Geräte direkt, d. h.
ohne einen zwischengeschalteten Ethernet-Hub oder -Switch, miteinander zu
verbinden. Verwenden Sie dieses Kabel nicht, wenn Sie das Ethernet-Gerät an
einen Ethernet-Hub oder -Switch anschließen.
•
4,3 m
•
Kategorie 5E
Pinbelegung der Kabelstecker
Das Kabel verfügt über zwei RJ45-Stecker.
Pinbelegung der RJ45-Stecker am Crossover-Ethernet-Kabel (RJ45-zu-RJ45)
RJ45-Pin
Signal
Richtung
RJ45-Pin
Signal
1
TX+
→
3
RX+
2
TX+
→
6
RX+
3
RX+
←
1
TX+
4
Nicht verwendet
–
4
Nicht verwendet
5
Nicht verwendet
–
5
Nicht verwendet
6
RX-
←
2
TX-
7
Nicht verwendet
–
7
Nicht verwendet
8
Nicht verwendet
–
8
Nicht verwendet
