Cable de cruce Ethernet
Español
2711P-CBL-EX04
Uso
Use los cables de comunicación para conectar dos dispositivos Ethernet
directamente, sin necesidad de un interruptor o conector Ethernet. No use este
cable cuando haga una conexión con un interruptor o conector Ethernet.
•
4.3 metros (14 pies)
•
Categoría 5E
Diagrama del cable
El cable tiene dos conectores RJ45.
Esquema de los pines del cable de cruce Ethernet RJ-45 a RJ-45
Pin
RJ-45
Señal
Dirección
Pin
RJ-45
Señal
1
TX+
→
3
RX+
2
TX+
→
6
RX+
3
RX+
←
1
TX+
4
No se usa
–
4
No se usa
5
No se usa
–
5
No se usa
6
RX-
←
2
TX-
7
No se usa
–
7
No se usa
8
No se usa
–
8
No se usa
