Page 5: Schema del cavo
5
Cavo Ethernet crossover
Italiano
2711P-CBL-EX04
Applicazione
Usare i cavi di comunicazione per connettere direttamente due dispositivi Ethernet
senza un hub o uno switch Ethernet. Non usare questo cavo per la connessione a
un hub o uno switch.
•
4,3 metri (14 piedi)
•
Categoria 5E
Schema del cavo
Il cavo ha di due connettori RJ45.
Piedinatura per cavo Eternet crossover da RJ-45 a RJ-45
Piedino
RJ-45
Segnale
Direzione
Piedino
RJ-45
Segnale
1
TX+
→
3
RX+
2
TX+
→
6
RX+
3
RX+
←
1
TX+
4
Non usato
–
4
Non usato
5
Non usato
–
5
Non usato
6
RX-
←
2
TX-
7
Non usato
–
7
Non usato
8
Non usato
–
8
Non usato
